Molded Chip Precision Shunt

Molded Chip Precision Shunt
Product Code : QESF-SJ
Price And Quantity
  • Minimum Order Quantity
  • 10
  • Unit of Measure
  • pieces
Product Specifications
  • Voltage Booster Type
  • current
  • Product Type
  • Current Transformer
Product Description

Backed by a team of experts, we are engaged in manufacturing and supplying a wide range of Molded Chip Precision Shunt to our clients. This is made at our well-developed production division incorporating fine grade material owing to which we are able to supply qualitative and distinctive precision shunt. This product finds applications in electronic circuitry designing to supply the standard value of current. Our patrons can avail the Molded Chip Precision Shunt at a highly cost-effective price from us within the promised time frame.

Molded Chip Precision Shunt

Model specification

Model

L (mm)

B (mm)

C (mm)

D (mm)

E (mm)

(W)

(mΩ)



QESF-1/2

5.1±0.5

3.2±0.2

1.0±0.2

2.5±0.4

1.3±0.2

0.5

1~400

1%


5%


10%

<50ppm/ºC

QESF-1

6.4±0.5

3.8±0.2

1.2±0.2

2.8±0.4

2.5±0.2

1

QESF-2

11.3±0.8

7.0±0.2

2.6±0.2

4.1±0.4

5.5±0.2

2

QESF-3

17.5±0.8

7.0±0.2

2.6±0.2

7.1±0.5

5.5±0.2

3

QESF-SJ

22.6±0.2

23.7±0.2

7.6±0.2

4.5±0.2

1.7±0.2

7

0.5~500

Performance index:

Test item

Specification

Test methods

Thermal shock

R 0.5%R

5PrºC/ 150ºC 15min, 1000 cycles

Over load

R 0.5%R

5Pr, SS

Low temperature storage

R 0.5%R

-65ºC, 25h

High temperature storage

R 1.0%R

275ºC, 1000h

Damp heat, steady state

R 0.5%R

40ºC, RH96±3%, 0.1Pr, 1000h

Mechanical shock

R 0.5%R

1000g, 6ms, 5cycles

Vibration

R 0.5%R

10~2000HZ,12h

Load life

R 2.0%R

70ºC, Pr, 1000h

Leaching

R 0.5%R

+260ºC, 10s



Trade Information
  • Payment Terms
  • Telegraphic Transfer (T/T)
  • Supply Ability
  • 1000000 Per Month
  • Delivery Time
  • 10 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples available with shipping and taxes paid by the buyer
  • Main Export Market(s)
  • Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • iso9001 ce
